brushless ECX Speed motors with an ironless winding have an extremely large speed range,
high power, excellent control characteristics and of course unrivaled durability.
The ECX SPEED 8 M is available with Hall sensors, encoder, or sensorless.
It can be combined with gearheads, and the electrical connection is configurable.
Nominal voltage 6 V
Nominal speed 26700 rpm
Stall torque 5.18 mNm
Terminal resistance 1.8 Ω
Speed constant 6160 rpm/V
Ambient temperature -20 to +85 °C
Bearing type ball bearings
Max. speed 50000 rpm
Weight 6 g
