Suitable for fixed installations both inside and outside railway vehicles (braking and traction)
UIC-Bus cable is also compatible with CAN field bus system
power supply, and data transmission
Test Voltage is1.5 kV AC (50 Hz / 1 min)
Temperature Range (Fixed Installation)is very flexible -40 °C to +90 °C
Maximum Voltage: U₀m = 0.72 kV AC, Um = 1.2 kV AC
Insulation Resistance is > 100 MΩ·km
outer sheet is made up of electron-beam cross-linked elastomer
excelent fire performance,Flame spread (bunched cables ≥12 mm)Carbonisation < 2.5 m
Halogen-free
